| Amperage Rating | : | 14.5 A |
| Compressor Type | : | BLDC Rotary |
| Cooling BTU Rating | : | 5500 to 20500 Btu/hr |
| Cooling Operating Temperature | : | 14 to 115 deg F |
| EER Rating | : | 11.5 |
| Finish | : | Galvanized |
| Frequency Rating | : | 60 Hz |
| HSPF Rating | : | 9 |
| Heating BTU Rating | : | 4100 to 23200 Btu/hr |
| Heating Operating Temperature | : | 5 to 75 deg F |
| Material | : | Steel |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 11-3/4 in |
| Overall Width | : | 41-15/16 in |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 17 |
| Series | : | Quantum Series |
| Voltage Rating | : | 208/230 V |
Works hard. Saves energy. The Quantum 17 SEER provides a quality and economical solution for heating or cooling a single room or zone.
Samsung Split System Outdoor Air Conditioner, Quantum Series, 208/230 V, 14.5 A, 60 Hz Frequency, Number of Fan Speeds: 3, Heating BTU Rating: 4100 to 23200 Btu/hr, Cooling BTU Rating: 5500 to 20500 Btu/hr, 11.5 EER, 17 SEER, 9 HSPF, BLDC Rotary Compressor, R-410A Refrigerant, Steel, Galvanized, Heating Operating Temperature: 5 to 75 deg F, Cooling Operating Temperature: 14 to 115 deg F, 41-15/16 in Overall Width, 11-3/4 in Overall Height
- Outdoor unit shall provide 208/230 V power to indoor unit via 14 AWG x 3 interconnect power cable
- Electro-static, washable, main filter as standard
- Indoor unit chassis shall be UL 94V0 with a galvanized steel mounting bracket
- The outdoor unit shall be galvanized steel with a baked on powder-coated finish for durability
- The indoor unit heat exchanger shall be mechanically bonded fin to copper tube
- The outdoor unit heat exchanger shall be aluminum, flat fin, micro channel
- The compressor shall be hermetically sealed, Inverter controlled, BLDC rotary
- Refrigerant flow shall be controlled by electronic expansion valve at outdoor unit
- The indoor fan shall be a single, anti-bacterial cross-flow-type
- Three fan speed settings and auto setting
- Automatic (motorized) vertical (up/down) swing louver
